EMAX ES3351 Series Digital Analog Servos
ES3301 - Plastic Gears / Analog - 21T
$4.34
Sale price
$4.34
Regular price
$7.00
Skip to product information
EMAX ES3351 Series Digital Analog Servos
$4.34
Sale price
$4.34
Regular price
$7.00
Here is the technical specification table extracted and completely translated into English:
Product Specifications Comparison
| Specifications | ES3301 Analog | ES3302 Metal Analog | ES3351 Digital | ES3352 Metal Digital |
| Servo Direction | CW / Normal | CW / Normal | CW / Normal | CW / Normal |
| Operating Voltage | 4.8–6.0V | 4.8–6.0V | 4.8–6.0V | 4.8–6.0V |
| Operating Signal | 1500–1900µsec | 1500–1900µsec | 1500–1900µsec | 1500–1900µsec |
| Wire Length | 25cm | 25cm | 25cm | 25cm |
| Plug Type | Futaba / JR | Futaba / JR | Futaba / JR | Futaba / JR |
| Gear Type | Plastic Gear | Metal Gear | Plastic Gear | Metal Gear |
| Speed | 0.12sec / 0.10sec / 60° | 0.12sec / 0.10sec / 60° | 0.12sec / 0.10sec / 60° | 0.12sec / 0.10sec / 60° |
| Dimensions | 23.1 × 9.1 × 24mm | 23.1 × 9.1 × 24mm | 23 × 12 × 24.5mm | 23 × 12 × 24.5mm |
| Weight | 10.6g | 12.4g | 10.6g | 12.4g |
| Torque | 2.0kgf / 2.2kgf | 2.4kgf / 2.8kgf | 2.0kgf / 2.2kgf | 2.4kgf / 2.8kgf |
