GDW DS635MG 35kg High Torque Servo

GDW DS635MG 35kg High Torque Servo

$39.96
$39.96 $54.00


  • The default angle for model RC transmitters is approximately 60°.

  • 90° Controllable Angle: Pulse width 1000–2000 µs.

  • 120° Controllable Angle: Pulse width 900–2100 µs. Commonly used for RC cars, RC airplanes, and RC boats.

  • 180° Controllable Angle: Pulse width 500–2500 µs. Suitable for robot joints and industrial development.

  • 270° Controllable Angle: Pulse width 500–2500 µs. Suitable for robot joints and industrial development.

  • 350° Controllable Angle: Pulse width 500–2500 µs. Equipped with a magnetic sensor potentiometer. Suitable for robot joints, heads, and industrial development.

  • 360° Continuous Rotation (Position Uncontrollable): Pulse width 500–2500 µs. Commonly used for winching/wire twisting and industrial development.

    Note: 1400–1600 µs represents the stopped state. Moving closer to 500 µs or 2500 µs yields higher speed and torque (faster rotation).

Features & Applications

  • Construction: Metal middle case, metal gears, coreless motor.

  • Applications: Suitable for RC fixed-wing aircraft, jet-powered planes, RC cars, etc.
