SunnySky X Series V3 X2212 V3 Long Shaft Brushless Motors

KV580 / Flat shaft

$12.40

$12.40 $18.50

SunnySky X Series V3 X2212 V3 Long Shaft Brushless Motors

$12.40

$12.40 $18.50

TYPE KV580 KV800 KV980 KV1250 KV1400 KV2450

SIZE Flat shaft Long axis

KV580:

Specifications	X2212-III
Stator Diameter	22mm
Stator Thickness	12mm
No.of Stator Slots	12
No.of Rotor Poles	14
Motor Kv	580
NO-Load Current(A/10V)	0.3A
Motor Resistance	267m2
Max Continuous Current	17A/30s
Max Continuous Power	425W
Weight	62g
Rotor Diameter	27.5mm
Body Length	30mm
Max Lipo Cel1	6S
ESC	20-30A

螺旋桨(inch)	电压(W）	电流(0	拉力(g)	转选(FM)	功率(W)	力效(g/0	Load temperature in 100% throttle
APC3060	22.2	0.6	100	3927	13.32	7.8
		1	150	4810	22.2	6.76
		1.4	200	5480	31.08	6.44
		1.8	250	6143	39.95	6.25
		2.3	300	6578	51.05	5.88
		2.9	350	110	64.39	5.4
		3.4	400	7577	75.48	.30
		4.5	500	8364	99.9	5.0
		5.9	600	9079	130.98	4.58
		7.4	200	9872	164.28	4.25
		8.8	770	10365	195.30	3.94
	25	0.5	100	3985	12.5	8.00
		0.8	150	479	20	7.50
		1.2	200	5400	30	6.67
		1.6	250	6050	40	6.25
		2.1	300	6602	52.5	5.71
		2.6	350	7140	65	5.38
		3	400	7506	75	5.33
		4.1	500	8476	1025	4.88
		5.4	600	9225	135	4.4
		6.8	700	9881	170	4.12
		3.6	800	10610	215	3.72
		10.6	920	11270	265	3.47	70010nin
AFC9080 APC9000	22.2	0.5	100	3130	11.1	.01
		0.8	150	3940	17.70	8.45
		1.1	200	4492	24.42	8.19
		1.5	250	4972	33.3	7.5L
		1.9	300	5410	42.18	7.11
		2.3	350	5806	51.05	6.65
		2.8	400	6176	62.16	6.44
		3.7	500	0815	82.14	6.09
		4.9	600	7420	108.78	5.52
		6.2	700	7847	137.64	5.09
		7.6	000	0376	160.72	4.74
		9.2	900	8838	204.24	4.4L
		11.5	1070	9557	255.3	4.19
	25	0.4	100	325	10.0	10.0
		0.7	150	3910	17.5	8.5
		1	200	4640	25.0	8.00
		1.4	250	497	35.0	7.14
		1.8	300	5496	45.0	6.67
		2.2	350	5822	55.0	6.36
		2.5	400	6180	63.8	6.27
		3.4	500	67802	85.0	5.0
		4.4	000	7302	110.0	5.45
		5.5	700	7890	137.5	5.09
		6.8	800	6340	170.0	4.71
		6.2	700	7867	137.64	5.09
		7.0	800	8376	168.72	4.74
		9.2	900	8858	204.24	4.41
		11.5	1070	955	255.3	4.19
	25	0.4	100	3250	10.0	10.00
		0.7	150	3910	17.5	8.57
			200	4540	25.0	8.00
		1.4	250	4975	35.0	7.14
		1.8	300	5440	45.0	6.67
		2.2	50	5022	55.0	6.35
		2.55	400	6180	63.8	6.27
		3.4	500	6782	85.0	5.88
		4.4	600	7362	110.0	5.45
		5.5	700	7890	137.5	5.09
		6.8	800	8340	170.0	4.71
		8.2	900	8806	205.0	4.39
		9.7	1000	9280	242-5	4.12
		13.6	1250	10390	340.0	3.68	80C inin
APC1047	22.2	0.4	100	2725	8.88	11.20
		0.经	150	3285	14.43	10.40
		0.9	200	3760	19.90	10.01
		1.2	250	4140	26.64	9.30
		1.6	300	4471	35.52	8.45
		1.9	350	480	42.18	8.30
		2.3	400	5048	51.00	7.83
		3.2	500	5590	71.04	7.04
		4.2	600	6025	93.24	6.44
		5.2	700	642	15.44	6.0
		6.4	800	6844	142.08	5.63
		7.8	900	7140	173.16	5.20
		9.4	1000	7604	208.68	4.79
		12.5	1200	8256	277.50	4.22
		14.9	1370	8618	330.78	4.14
	25	0.3	100	2701	7.50	13.33
		0.5	150	3262	12.50	12.00
		0.8	200	3722	20.00	10.00
		1.1	250	4129	27.50	9.09
		1.4	300	4468	35.00	8.5T
		1.7	350	4765	42.50	8.24
		2.1	400	5074	52.50	7.62
		2.9	500	5540	72.50	.90
		3.8	600	6004	95.00	6.22
		4.7	700	0514	117.50	5.90
		5.9	800	6878	147.50	5.42
		7.1	900	185	T	5.07
		8.5	1000	7629	212.50	4.71
		11	1200	8346	275.00	4.36
		14.7	1400	8874	367.50	3.81
		17.5	1580	9229	437.50	3.61	760253

KV800:

Specifications	X2212III
Stator Diameter	22mm
Stator Thickness	12mm
No.of Stator Slots	12
No.of Rotor Poles	14
Motor Ky	800
N0-Load Current(A/10V)	0.46A
Motor Resistance	125m2
Max Continuous Current	24A/30s
Hax Continuous Power	403.2w
Veight	59g
Rotor Diameter	27.5mm
Body Length	30mm
Hax Lipo Cel1	3-4S
ESC	30A

螺旋桨(英寸)	电压 C	电流(A)拉力(g)		功率(T)	力效(g/0	转速(BPI)	Load temperature in 100% throttle
GF 9045	11.1	0.8	100	8.88	11.26	3398
		1.8	200	19.98	10.01	4837
		3.2	300	35.52	8.45	585T
		4.8	400	53.28	7.5	694
		6.6	500	73.26	5.83	1443
		7.8	560	86.58	6.47	7867
	12.5	0.7	100	8.75	11.43	3415
		1.7	200	21.25	3.41	4881
		2.8	300	35	8.57	5873
		4.3	400	53.75	7.44	6549
		6	500	75	3.67	7420
		7.8	600	97.5	4.15	090
		9.6	680	120	5.6	9661
	148	0.6	100	8.88	11.26	3405
		1.4	200	20.72	9.65	4809
		2.4	300	35.52	8.45	5824
		3.6	400	53.28	7.5	6082
		5.1	500	75.48	6.62	7403
		6.5	600	96.2	6.24	8002
		10.6	800	156.88	5.10	9225
		12.8	920	189.44	4.80	9828
	16.8	0.6	100	10.03	9.92	344
		1.3	200	21.0	9.16	480
		2.2	300	30.90	8.12	5836
		3.3	400	55.44	7.22	6702
		4.5	500	75.6	6.61	7415
		5.9	600	99.12	6.05	204
		9.3	800	156.24	5.12	9218
		13.5	1000	226.8	4.41	10212
		15.7	1110	263.75	4.21	10801	58°C
GF9060	11.1	0.8	100	8.88	11.26	3072
		1.9	200	21.09	9.48	4318
		3.4	300	37.74	7.95	5133
		5.3	400	58.83	3.80	5825
		7.5	500	83.5	6.0	6756
		10.7	625	118.77	5.26	7386
	12.5	0.7	100	8.75	11.43	0035
		1.8	200	22.5	8.89	4290
		3.2	300	4	7.50	5121
		4.8	400	60	6.67	5897
		6.8	500	85	5.88	6680
		9.3	600	116.25	5.16	1316
		12.0	730	160	4.56	9002
	14.8	0.6	100	8.88	11.26	3095
		1.5	200	22.2	9.01	4325
		2.7	300	39.9	7.51	5211
		4.1	400	60.68	6.59	5939
		5.9	500	87.2	5.73	6692
		7.9	600	116.92	5.13	T302
		13.1	300	193.88	4.13	86
		16.9	930	250.12	3.72	9070
	16.8	0.6	100	10.08	9.92	3102
		1.4	200	23.52	8.50	4375
		2.3	300	38.64	7.76	5194
		3.8	400	63.04	6.27	5955
		5.1	500	85.68	5.84	6684
		7.1	600	119.20	5.03	7265
		11.6	800	194.88	4.11	8391
		17.9	1000	300.72	3.33	9321
		20.8	1130	349.44	3.23	9943	2nin 700
AFC 1047	11.1	0.6	100	6.66	15.02	2600
		1.6	200	17.70	11.20	2022
		2.7	300	29.97	10.0L	4372
		4.1	400	45.51	8.79	4947
		5.7	500	63.27	7.90	542
		7.5	600	83.25	7.21	5881
		13.2	870	146.2	5.94	6951
	12.5	0.6	100	7.5	13.33	2625
		L.4	200	17.5	11.43	3616
		2.5	300	31.25	9.60	469
		3.7	400	46.25	8.65	4969
		5.2	500	65	7.09	5448
		6.9	600	86.5	6.86	5014
		10.7	800	133.75	5.90	6745
		15.4	1020	192.5	5.30	7511
	148	0.5	100	7.4	13.51	2
		1.2	200	17.75	11.26	5017
		2.1	300	31.08	9.65	4367
		3.1	400	45.83	3.72	4908
		4.4	500	65.12	7.08	5484
		5.7	600	84.35	7.11	5887
		9	800	133.2	5.0	6719
		13.1	1000	193.88	5.16	7429
		18.4	1200	272.32	4.41	8170
		20.2	1220	298.96	4.42	843
	16.8	0.5	100	8.4	11.90	2633
		1.1	200	18.43	10.82	3605
		1.9	300	31.90	9.40	4377
		2.8	400	47.04	8.50	4926
		4	500	67.2	7.44	5456
		5.1	600	85.68	7.00	5005
		8	800	134.4	5.96	6739
		11.5	1000	193.2	5.18	749
		16	1200	208.8	4.46	8165
		21.7	1400	364.56	3.84	8753
		233	1520	391.44	3.88	9115	1nin 700

KV980：

Stator Diameter	22mm	Rotor Diameter	27.5mm
Stator Thickness	12mm	Body Length	30mm
No.of Stator Slots	12	Max Lipo Cell	3-4S
No.of Rotor Poles	14	ESC	20-30A
Motor Kv	980	Recommended Prop(inch)	APC8038 /APC1038 /APC1047 /APC9047/APC9045
No-load current	0.6A/10V	Single weight for multirotors	400g ( 3-4S 1038\1047 )
Motor Resistance	92mΩ	Single weight for multirotors	500g ( 4S 8038\8043\8045\9047)
Max Continuous Current	26A/30s	Weight for training airplane	750g (3S 1047)
Max Continuous Power	385W	Weight for 3D airplane	550g (3S 1047)
Weight	57g

Prop(inch)	Voltage(V)	Amps(A)	Thrust(gf)	Watts(W)	Efficiency(g/W)	RPM	Load temperature in 100% throttle
APC8038	14.8	0.7	100	10.36	9.65	4120	55℃ 10min
		1.7	200	25.16	7.95	5641
		2.8	300	41.44	7.24	6668
		4	400	59.2	6.76	7629
		5.4	500	79.92	6.26	8440
		7.1	600	105.08	5.71	9154
		8.7	700	128.76	5.44	9766
		10.2	800	150.96	5.30	10436
		16.4	1075	242.72	4.43	11910
APC9045	11.1	0.9	100	9.99	10.01	3406	55℃ 10min
		2.1	200	23.31	8.58	4827
		3.3	300	36.63	8.19	5789
		4.8	400	53.28	7.51	6642
		6.5	500	72.15	6.93	7370
		12.2	785	135.42	5.80	9308
	14.8	0.6	100	8.88	11.26	3452
		1.5	200	22.2	9.01	4734
		2.7	300	39.96	7.51	5780
		3.8	400	56.24	7.11	667
		5.2	500	76.96	6.50	746
		6.6	600	97.68	6.14	8140
		8.4	700	124.32	5.63	8649
		10	800	148	5.41	9150
		11.9	900	176.12	5.11	9696
		14	1000	207.2	4.83	11368
		16	1100	236.8	4.65	10221
		18.2	1220	269.36	4.53	10649
APC9047	11.1	0.8	100	8.88	11.26	3288	76℃ 10min
		1.9	200	21.09	9.48	4580
		3.2	300	35.52	8.45	5638
		4.9	400	54.39	7.35	6591
		6.4	500	71.04	7.04	7301
		8.2	600	91.02	6.59	8041
		10.4	700	115.44	6.06	9396
		13.2	840	146.52	5.73	8730
	14.8	0.6	100	8.88	11.26	3231	70℃ 10min
		1.5	200	22.2	9.01	4643
		2.5	300	37	8.11	5605
		3.8	400	56.24	7.11	6432
		5	500	74	6.76	7378
		6.5	600	96.2	6.24	8090
		8.2	700	121.36	5.77	8730
		10	800	148	5.41	9366
		11.7	900	173.16	5.20	10131
		13.8	1000	204.24	4.90	10716
		18.4	1250	272.32	4.59	11755
APC1038	11.1	0.7	100	7.77	12.87	2813	76℃ 10min
		1.8	200	19.98	10.01	3866
		3	300	33.3	9.01	4636
		4.6	400	51.06	7.83	5170
		6.3	500	69.93	7.15	5687
		8.1	600	89.91	6.67	6100
		10.2	700	113.22	6.18	6591
		12.4	800	137.64	5.81	6853
		15.3	900	169.83	5.30	7262
		20.2	1130	224.22	5.04	7923
APC1047	11.1	0.7	100	7.77	12.87	2612	85℃ 15S
		1.7	200	18.87	10.60	3605
		3	300	33.3	9.01	4264
		4.5	400	49.95	8.01	4887
		6.4	500	71.04	7.04	5418
		8.3	600	92.13	6.51	5872
		10.45	700	115.99	6.03	6335
		12.7	800	5	5.67	6983
		15.3	900	140.97	5.30	7378
		19.9	1100	169.83	4.98	7748
	14.8	0.5	100	220.89	13.51	2600
		1.3	200	7.4	10.40	3593
		2.2	300	19.24	9.21	4253
		3.4	400	32.56	7.95	4869
		4.9	500	50.32	6.89	5381
		6.5	600	72.52	6.24	5845
		8.7	700	96.2	5.44	6332
		10.5	800	128.76	5.15	6610
		12.4	900	155.4	4.90	7055
		14.7	1000	183.52	4.60	7444
		16.4	1100	217.56	4.53	7766
		18	1200	242.72	4.50	8100
		20.6	1300	266.4	4.26	8394
		24.5	1400	304.88	3.86	8620
		27.4	1500	362.6	3.70	8900
		29	1650	405.52	3.84	9409

KV1250:

Stator Diameter	22mm	Rotor Diameter	27.5mm
Stator Thickness	12mm	Body Length	30mm
No.of Stator Slots	12	Max Lipo Cell	3-4S
No.of Rotor Poles	14	ESC	30-40A
Motor Kv	1250	Recommended Prop(inch)	APC8060 /APC7060 /APC9047/APC9060
No-load current	0.8A/10V	Weight for aerobatics airplane	750g (3S 9047\9060\9045\8060)
Motor Resistance	54mΩ	Weight for 3D airplane	550g (3S 9047\9045)
Max Continuous Current	35A/30s
Max Continuous Power	518W
Weight	59g

Prop (inch)	Voltage (V)	Amps (A)	Thrust (gf)	Watts (W)	Efficiency (g/W)	RPM	Load temperature in 100% throttle
APC9047	11.1	0.8	100	8.88	11.26	3215	65℃ 10min
		2	200	22.2	9.01	4595
		3.3	300	36.63	8.19	5659
		5.1	400	56.61	7.07	6569
		6.8	500	75.48	6.62	7337
		8.8	600	97.68	6.14	8041
		10.9	700	120.99	5.79	8934
		13.5	800	149.85	5.34	9510
		16	900	177.6	5.07	10102
		18.9	1000	209.79	4.77	10765
		23.6	1220	261.96	4.66	11475
APC9045	11.1	0.9	100	9.99	10.01	3451	63℃ 10min
		2.1	200	23.31	8.58	4722
		3.6	300	39.96	7.51	5767
		5.1	400	56.61	7.07	6665
		6.9	500	76.59	6.53	7409
		9	600	99.9	6.01	8035
		11	700	122.1	5.73	8581
		13.5	800	149.85	5.34	9286
		16.2	900	179.82	5.01	9690
		19.2	1000	213.12	4.69	10170
		25.5	1210	283.05	4.27	11234
APC9060	11.1	0.9	100	9.99	10.01	3185	60℃ 10min
		2.2	200	24.42	8.19	4414
		3.9	300	43.29	6.93	5287
		5.7	400	63.27	6.32	6129
		7.9	500	87.69	5.70	6765
		10.1	600	112.11	5.35	7390
		12.5	700	138.75	5.05	7881
		15	800	166.5	4.80	8393
		18.3	900	203.13	4.43	8990
		22	1000	244.2	4.10	9402
		25.5	1100	283.05	3.89	9887
		31.2	1290	346.32	3.72	10547
APC8060	11.1	1.2	100	13.32	7.51	3829	77℃ 30S
		3	200	33.3	6.01	5533
		5.1	300	56.61	5.30	6544
		7.1	400	78.81	5.08	7561
		9.2	500	102.12	4.90	8315
		12	600	133.2	4.50	9094
		15.6	700	173.16	4.04	9840
		18.7	800	207.57	3.85	10403
		24	950	266.4	3.57	11277
	14.8	0.9	100	13.32	7.51	3897
		2.2	200	32.56	6.14	5490
		3.7	300	54.76	5.48	6622
		5.4	400	79.92	5.01	7560
		7.1	500	105.08	4.76	8484
		9.1	600	134.68	4.46	9134
		12.1	700	179.08	3.91	9908
		15.15	800	224.22	3.57	10486
		18.3	900	270.84	3.32	11119
		22.5	1000	333	3.00	11586
		25.4	1100	375.92	2.93	12147
		29.3	1200	433.64	2.77	12573
		34.8	1350	515.04	2.62	13427

KV1400:

Stator Diameter	22mm	Rotor Diameter	27.5mm
Stator Thickness	12mm	Body Length	30mm
No.of Stator Slots	12	Max Lipo Cell	3-4S
No.of Rotor Poles	14	ESC	30-40A
Motor Kv	1400	Recommended Prop(inch)	APC8038 /APC7060 /APC8060 /APC9047/APC9045
No-load current	1A	Weight for aerobatics airplane	750g (3S 9047\9045\8060) (4S 7060)
Motor Resistance	43mΩ
Max Continuous Current	37A/30s
Max Continuous Power	560W
Weight	57g

Prop(inch)	Voltage(V)	Amps(A)	Thrust(gf)	Watts(W)	Efficiency(g/W)	RPM	Load temperature in 100% throttle
APC9047	11.1	1	100	11.1	9.01	3244	77℃3min
		2.1	200	23.31	8.58	4590
		3.6	300	39.96	7.51	5651
		5.4	400	59.94	6.67	6509
		7.3	500	81.03	6.17	7383
		9.3	600	103.23	5.81	8061
		11.3	700	125.43	5.58	8839
		13.4	800	148.74	5.38	9476
		16.1	900	178.71	5.04	10002
		18.8	1000	208.68	4.79	10550
		21.4	1100	237.54	4.63	11250
		24.8	1200	275.28	4.36	11700
		30.5	1380	338.55	4.08	12423
APC8038	11.1	1	100	11.1	9.01	4002	66℃10min
		2.5	200	27.75	7.21	5595
		4.1	300	45.51	6.59	6683
		5.8	400	64.38	6.21	7620
		7.6	500	84.36	5.93	8404
		9.9	600	109.89	5.46	9145
		12.3	700	136.53	5.13	9798
		15	800	166.5	4.80	10389
		18	900	199.8	4.50	10992
		20.4	1000	226.44	4.42	11503
		23.8	1100	264.18	4.16	11963
		28	1230	310.8	3.96	12455
APC9045	11.1	1	100	11.1	9.01	3340	75℃ 3min
		2.2	200	24.42	8.19	4705
		3.8	300	42.18	7.11	5795
		5.5	400	61.05	6.55	6688
		7.3	500	81.03	6.17	7419
		9.4	600	104.34	5.75	8060
		11.5	700	127.65	5.48	8774
		14	800	155.4	5.15	9264
		17	900	188.7	4.77	9796
		19.8	1000	219.78	4.55	10286
		22.8	1100	253.08	4.35	10710
		26.4	1200	293.04	4.10	11152
		29.7	1300	329.67	3.94	11600
		31.8	1440	352.98	4.08	12100
APC8060	11.1	1.2	100	13.32	7.51	3890	65℃ 10min
		2.9	200	32.19	6.21	5456
		5	300	55.5	5.41	6606
		7.2	400	79.92	5.01	7564
		9.3	500	103.23	4.84	8340
		12	600	133.2	4.50	9142
		15.9	700	176.49	3.97	9820
		20.4	800	226.44	3.53	10425
		25.6	900	284.16	3.17	11027
		30.2	1050	335.22	3.13	12025
APC7060	11.1	1.7	100	18.87	5.30	4957	71℃ 1min30s
		3.7	200	41.07	4.87	6990
		6.3	300	69.93	4.29	8444
		8.8	400	97.68	4.10	9731
		12	500	133.2	3.75	10895
		15.9	600	176.49	3.40	11826
		21.3	750	236.43	3.17	13244
	14.8	1.3	100	19.24	5.20	4932
		2.8	200	41.44	4.83	6995
		4.7	300	69.56	4.31	8481
		6.7	400	99.16	4.03	9772
		9	500	133.2	3.75	10878
		11.8	600	174.64	3.44	11848
		14.6	700	216.08	3.24	12964
		18.3	800	270.84	2.95	13774
		22.2	900	328.56	2.74	14584
		25.9	1000	383.32	2.61	15238
		30.6	1100	452.88	2.43	16371
		34.4	1210	509.12	2.38	16243

KV2450:

Specifications				X2212-III
Stator Diameter				22mm			定子外径
Stator Thickness				12mm			定子厚度
No.of Stator Slots				12			定子槽数
No.of Rotor Poles				10			转子极数
Motor Kv				2450			电机KV
NO-Load Current(A/10V)				1.7A			空载电流
Motor Resistance				27mΩ			电机电阻
Max Continuous Current				32A/30s			最大连续电流
Max Continuous Power				355w			最大连续功率
Veight				58g			重量
Rotor Diameter				27.5mm			转子直径
Body Length				30mm			电机长度
Max Lipo Cel1				3S			支持锂电节数
ESC				30-40A			建议使用电调
Recommend Prop(inch)				HQ50456045			推荐螺旋桨规格
螺旋桨(英寸)	电压(V)	电流(A)	拉力(g)	功率(W)	力效(g/)	转速(RPM)	全油门负载温度
HQ 5045	11.1	2	100	22.2	4.50	7869
		4.6	200	51.06	3.92	11104
		7.6	300	84.36	3.56	13380
		10.9	400	120.99	3.31	15672
		14.6	500	162.06	3.09	17643
		18.5	600	205.35	2.92	19187
		22.8	700	253.08	2.77	20612
		26.7	790	296.37	2.67	21728
	12.5	1.8	100	22.5	4.44	7871
		4.2	200	52.5	3.81	11117
		6.9	300	86.25	3.48	13360
		10	400	125	3.20	15629
		13.6	500	170	2.94	17657
		17.4	600	217.5	2.76	19228
		21.5	700	268.75	2.60	20644
		25.1	800	313.75	2.55	22127
		32.3	950	403.75	2.35	24040	55℃
HQ 6045	11.1	1.8	100	19.98	5.01	6604
		3.9	200	43.29	4.62	9215
		6.3	300	69.93	4.29	11280
		8.9	400	98.79	4.05	12913
		12	500	133.2	3.75	14554
		15.3	600	169.83	3.53	15901
		18.6	700	206.46	3.39	17151
		22.1	800	245.31	3.26	18207
		25.8	900	286.38	3.14	19243
		32.2	1050	357.42	2.94	20642	2nin 70℃

Your cart is empty

SunnySky X Series V3 X2212 V3 Long Shaft Brushless Motors

You may also like

Join our email list
