Hengji MD260 2kg Metal Gear Servo
$12.00
Sale price
$12.00
Regular price
$15.00
| Specifications | MD260 |
| Product Name | Hengji 12g 180° FPV Gimbal Metal Gear Digital Servo MD260 |
| Application | MD260 FPV Gimbal Dedicated Digital Servo |
| Operating Voltage | 4.5V - 6.0V |
| Operating Temperature | -20°C to +60°C |
| Operating Speed |
0.10 sec/60° @ 6V 0.12 sec/60° @ 4.8V |
| Torque |
2.0kg.cm @ 6V 1.8kg.cm @ 4.8V |
| Idle Current | 5mA |
| Operating Current | 50-150mA |
| Stall Current | 600mA |
| Dead Band Width | $\leqslant$ 4usec |
| MAX Operating Travel | 90° / Single side pulse travel 400us |
| MAX Rotation Angle | 260° (Full travel) |
| Dimensions | 22.5 $\times$ 11.5 $\times$ 24.6mm |
| Weight | 12g |
| Bearing | Metal |
| Gears | 4 Metal Gears, 1 Nylon Gear |
| Connector Wire Length | 21cm |
